Detuning Reactor

Rated frequency

50Hz

Insulation/heat-resisting class

F/H class

Temperature rise limit

≤75K

Overload capacity

Long-term operation under 1.35times of rated current

Reactance deviation

A. Deviation of filter reactance under power frequency    rated current: 0~2%;

B. Each-phase reactance of 3-phase reactor is no more    than ±2% of 3-phase average value;

C. The difference between reactance and rated        reactance is no more than 3% under1.8times of power frequency rated current

Insulation

3KV/60S（50Hz）

Noise

≤48dB

Service conditions

Ambient temperature:-40℃≤T≤50℃

Altitude: ≤1000m

Relative humidity:≤95%

Loss

15W/kvar

Linearity

1.8In
